Spot Reflecting Galvanometer for Physics Lab

Spot Reflecting Galvanometer is designed for use as a DC null detector in Wheatstone bridges and potentiometers. The instrument features a built-in lamp and scale arrangement for convenient and accurate observation.

The highly sensitive moving coil system is suspended using a taut-band arrangement in the uniform field of a permanent magnet. The spot of light can be adjusted to any position on the scale using the zero-adjustment knob.

Physics Lab Experiments Setup from Atico Exports.

Packaging Type :

• Corrugated Box

Material :

• Plastic

Power Supply :

• AC Mains

Usage / Application :

• Laboratory

Power Supply :

• 220 V AC, 50 Hz
• Can Also Operate on a 6 V Battery

Light Source :

• 6 V, 0.3 A Bulb
• Produces a Bright Spot on the Scale

Construction :

• Built-in Lamp and Scale Arrangement
• Housed in a Bakelite Case
• Highly Sensitive Moving Coil System
• Taut-Band Suspension
• Permanent Magnet with Uniform Magnetic Field

Scale :

• Length: 150 mm
• End-Zero Type

Zero Adjustment :

• Zero-Adjustment Knob Provided
• Allows the Light Spot to Be Set at Any Point on the Scale

Sensitivity Control :

• 2-Pole, 6-Way Switch

Switch Positions :

• D
• 1/10
• 1/100
• 1/1000
• S/C
