This Steam to Water Heat Exchanger Unit has been designed to provide visual and quantitative results related to heat transfer in shell and tube type water cooled condensers.
Technical Specifications
Panel: High quality ABS
Digital Thermometer: 0.1°C resolution
Differential Pressure transducer and display
Flow meters x 2: 10 to 90 cm³/s and 1 to 12 g/s
Pressure Gauge: -100 to +100 kN/m²
Safety Features:
Steam chamber pressure relief valve
Pressure switch and heater high temperature cut out
