STEM Science Kits for Sensor Ballistic Pendulum

This setup consists of a launcher and a ballistic pendulum accessory mounted on a rotary motion sensor. The full motion of the pendulum swing can be recorded and graphed.
It allows the standard ballistic pendulum experiment to be performed, where the muzzle velocity of the ball is determined from the maximum height reached by the pendulum.
The setup can also be used to compare a completely inelastic collision, where the ball is captured by the pendulum, with a partially inelastic collision, where the ball rebounds.
Additionally, it enables verification that the angular momentum of the ball about the pivot point is equal to the combined angular momentum of the ball and pendulum immediately after the collision.

Perform These Experiments :

• Inelastic Collisions
• Ballistic Pendulum
• Conservation of Angular Momentum and Energy in a Ballistic Pendulum
• Projectile Motion
• Projectile Range vs. Launch Angle
• Conservation of Energy of a Projectile Launched Straight Up
• Conservation of Momentum in Two Dimensions
• Path of a Projectile

What's Included :

• 1x Mini Projectile Launcher
• 1x Mini Ballistic Pendulum Accessory
• 1x Wireless Rotary Motion Sensor
• 1x Wireless ISmart Gate
• 1x Photogate Mounting Bracket
• 1x Stainless Steel Rod, 60 cm Threaded
• 1x Aluminum Table Clamp
• 1x Rod Clamp for Rotary Motion Sensor
