Stirred Fluid Loss Tester oil and petroleum testing instruments by ATICO EXPORT

The stirred fluid loss tester provides a reliable means of determining the fluid loss characteristics of well cements. The ergonomic and easy-to-use design can condition and test cement slurries under HTHP conditions and in accordance with API Spec 10 guidelines. An innovative sealing system eases cleanup and extends the usable life of consumable parts.

Maximum temperature :

• 450°F (232.2°C)

Maximum pressure :

• 2,000 PSI (13.8 MPa)

Digital temperature controller :

• 1.0° resolution

Slurry cup rotational speed :

• Variable up to 200 RPM

Crated size :

• Approx. 38” × 26” × 34” (97 × 66 × 86 cm)

Crated weight :

• Approx. 220 lb (99.8 kg)

Requirements :

Electrical :

• 120-Volt, 60 Hz, 18-Amp
• 220-Volt, 50 Hz, 10-Amp

Nitrogen supply :

• 2,000 PSI - 2,500 PSI (13.8 MPa – 17.2 MPa)

Water supply for cooling :

• 40 PSI

Water drain :

• required

• Temperature is maintained by PID temperature controller
• Filtration portion of the cell is dimensionally equivalent to an API approved HTHP test cell
• Cell cooling integrated into heat jacket
• Conforms to API Specification 10 guidelines
• Cell volume: 500 mL
