Students Science kit Solar cellfor Lab Use in Schools & Colleges ATICO Export

For school experiments using solar cells, which can be carried out within the time frame of a single lesson.
The various elements are designed to be particularly simple and easy to understand and can be handled with ease by groups of pupils. No other equipment is necessary except for the provision of additional sources of light to illuminate the solar cells at times of year when there is less sunlight available, along with simple school measuring instruments to measure electrical quantities.

The experiments that can be carried out include the following :

• No-load voltage and short-circuit current
• Series- and parallel connection
• Power characteristic line of a solar generator
• Influence of illuminance and of the illumination angle
• Conversion of solar energy to mechanical energy and to luminous energy
• Solar production of hydrogen

Included items :

• 1 × Plastic dish 95x62x20 mm
• 6 × Solar cell
• 1 × Electric motor with propeller in block
• 1 × °Glass with common salt (sodium chloride)
• 1 × Carton for plastic box 270x230x55 mm (int.dim.)
• 1 × Plastic box 260x197x55 mm
• 1 × Foam insert 260x200x35 mm
• 1 × Lidfoam, grey 260x200x10 mm
• 1 × LED, plug-in element
