Supply unit for chemical reactors

The reactor is the core element of a chemical production facility. In the reactor, the starting substances (reactants) react with each other to form a new substance (product). The reactor has to guarantee the conditions for an optimal reaction process. This primarily concerns the temperature in the reactor. Different types of reactors are used, depending on the requirements.

• supply unit for 6 different chemical reactor types
• connection of the reactors via hoses with quick-release couplings
• water circuit with tank, heater, temperature controller, pump and low water cut-off for heating and cooling (with WL 110.20 water chiller)
• temperature control of the reactants and reactors
• 3 glass tanks for reactants and products
• 5 peristaltic pumps to deliver the reactants and products
• 2 combined sensors for measuring the conductivity and temperature
• software for data acquisition via USB under Windows 11
