Surface Soil Sampler Set

Standards Compliance :

• Complied as per ASTM D2937, CNR No.22, BS 1377-9

Application :

• Used to take field samples of compacted fill or undisturbed soils and to evaluate density of compaction samples as the ground surface.

Construction :

• Steel made, galvanized against corrosion.

ASTM/CNR Version :

• The ASTM/CNR version, two models are available.
• Both of Surface Soil Sampler (Core Cutter) Sets (° 3– and ° 4–) consists of a drive head, 5 kg drive hammer and a thin wall sampling tube.
• 5 kg sliding weight drop hammer makes a free-fall on to the driving head which is placed on top of the sampling tube.

BS Version :

The BS version, two models are available.

• 100 mm Surface Soil Sampler (Core Cutter) Set consists of a driving dolly, 13,5 kg driving rammer and ° 100 mm x 130 mm high core cutter.
• 150 mm Surface Soil Sampler (Core Cutter) Set consists of a driving dolly, 16 kg driving rammer and ° 150 mm x 180 mm high core cutter.

Driving Rammer (kg) :

• AECE2337/A - 10
• AECE2337/B - 16
• AECE2337/C - 5
• AECE2337/D - 5
