System for data acquisition

This system for data acquisition is an addition to the TM 150 vibration trainer and makes it possible to analyse vibration signals on a PC. Frequency and phase response curves can be easily generated, saved and output using this system. The system also offers all the essential functions of a digital storage oscilloscope and can calculate the frequency spectra of the signals. Learn about System for data acquisition Engineering Mechanics Trainers India for optimal educational outcomes..

• data analysis for TM 150
• measurement, recording and analysis of frequency response and transfer function
• functions as a digital storage oscilloscope
• interface box with 3 sensor inputs and 3 analogue outputs
• 1 inductive displacement sensor (amplitude), 1 reference sensor (exciter force)
• software for data acquisition via USB under Windows 11
