Tag Open Cup Flash Tester for Oil Fuel and Petroleum Testing Instruments

The Tag Open Cup Flash and Fire Point Tester determines the flash and fire points of liquids at temperatures up to 325°F (163°C), as well as the flash points of cutback asphalts at temperatures below 200°F (93°C). The instrument includes a sample test cup, plated brass liquid bath with constant-level overflow, pivoting ignition taper with pilot light and reference bead, pivoting thermometer holder, heater, and cast-aluminum base. The electrically heated model features stepless variable heat control for accurate adjustment of the temperature rise rate according to applicable specifications. A gas-heated model is also available. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum flash and fire point testing applications.

Testing Temperature Range:

• Up to 325°F (163°C) for flash and fire point determination
• Below 200°F (93°C) for flash point determination of cutback asphalts

Heating Options:

• Electric heating
• Gas heating

Power Supply:

• 115 V, 60 Hz, single phase, 13 A
• 220–240 V, 50/60 Hz, single phase, 0.6 A

Construction and Features:

• Sample test cup
• Plated brass liquid bath with constant-level overflow
• Pivoting ignition taper with pilot light and reference bead
• Pivoting thermometer holder
• Heater with cast-aluminum base
• Stepless variable heat control on the electrically heated model

Dimensions (W × D × H):

• 10 × 17.5 × 11.5 inches (25.4 × 44.5 × 29.2 cm)

Net Weight:

• 20 lbs (9.1 kg)
