Television Trainer

The TV is mounted on an attractive chassis which allows the main printed circuit board to be exposed for ease of work
The circuit board features a plexiglass cover which has openings for access to all test points so as to allow insertion of probes while protecting the student and the circuit board
The trainer allows access to all the factory recommended key points for the taking of measurements, analysis and adjustments, the results of which are readily observable
The teaching program is designed to follow the service procedures as recommended by the manufacturer and uses the factory service manual in conjunction with student job sheets along with a test tool selection service manual

Suitable for learning about television operation, theory, repair and servicing

• Special attention is given to fault diagnosis so as to facilitate the teaching of troubleshooting techniques
• A unique fault insertion system is built into the trainer for student instruction purposes
• The system features a schematic block diagram silk screened onto an integral fault board that utilizes LEDs to indicate the nature and location of the fault
