Test stand for gears Deluxe

The MT 173 unit is used to investigate the functionality of different gears. The test stand consists of a drive unit and a brake unit. Four different gears are available as accessories. Learn about Test stand for gears for educational labs for optimal educational outcomes.. Driving and braking power are calculated to determine the efficiencies. The components used are common in drive systems and therefore have a high level of practical relevance. Learn about Test stand for gears equipment for optimal educational outcomes..

• determination of mechanical efficiency of gears
• spur and worm gear, spur gear, bevel gear, planetary gear available as accessories
• plant control with PLC via touch screen
• integrated router for operation and control via an end device and for screen mirroring: mirroring of the user interface on up to 5 end devices
• three-phase motor with variable speed via frequency converter
• air-cooled magnetic particle brake with adjustable braking torque
• inductive speed sensor on the motor and brake
• display of speed and torques
• data acquisition via PLC on internal memory, access to stored measured values via WLAN/LAN with integrated router/LAN connection to customer’s own network or direct LAN connection without customer network
