Theodolite - Electronic

The unit is a precision instrument for measuring angles in the horizontal and vertical planes. They are mainly used for surveying applications and have been adapted for specialised fields like meteorology and rocket launch technology.

Magnification :

• 30X

Objective Lens :

• 45 mm

Overall Length :

• 157 mm

Stadia Ration :

• 100

Stadia Constant :

• 0

Image :

• Erect

Field of View :

• 1° 30"

Minimum Focus :

• 1.4 mtr.

Resolving Power :

• 3.0'

Electronic Angle Measurement :

• Reading System Photoelectric detection by incremental encoder

Diameter of Circle :

• 79 mm

Minimum Reading :

• 1"/5" (Selectable)

Accuracy :

• 2"

Vertical &Horizontal Angle :

• Dual

Display :

• LCD Display, LCD Segment : 2 sides in two lines

Level Sensitivity Plate Level :

• 30" per 2mm (30"/2mm)

Circular Level :

• 8" per 2mm (8'/2mm)

Auto Vertical Compensator System :

• Liquid-electric detection/plate level selectable

Working Range :

• • 3'

Accuracy :

• Liquid Electric Detection, 1"

Plate Level :

• 30"/2mm
