Thermal Conductivity of Copper by Angstrom Method

Thermal Conductivity of Copper by Angstrom’s Method setup is designed to study and determine the thermal conductivity of a copper rod using Angstrom’s method.

Physics Lab Experiments Setup from Atico Exports.

Apparatus Used :

Experimental Setup :

• 0 to 50 V and 0 to 4 A AC Power Supply
• Voltmeter and Ammeter
• Built-in Signal Generator Providing a Square Wave Signal to the Power Supply
• Time Period: 38 Seconds

Sample Rod :

• Copper Rod
• Length: 50 cm
• Diameter: 2.5 cm
• Fitted Inside a Wooden Box to Minimize Energy Loss

Heater Coil :

• Fitted on the Copper Rod

Thermometer :

• Temperature Range: 0 to 200°C
• Quantity: 3

Additional Components :

• Stop Clock
• Connecting Leads
