Thermal Conductivity Physics Lab Experiment Setup by ATICO EXPORT

This experiment system is designed for the study of thermodynamics and heat transfer phenomena. It enables students to investigate fundamental thermal properties of solids and liquids through a series of practical experiments. The system integrates temperature measurement, energy measurement, mass determination, and controlled heating functions, providing an effective platform for understanding heat-related principles and experimental techniques.

Manufactured by Atico Export India.

Experimental Principle and Content

• Determination of Specific Heat Capacity of Liquids
• Measurement of Specific Heat Capacity of Solids by Electrothermal Method
• Determination of Thermal Equivalent of Power
• Measurement of the Heat of Vaporization of Water by Electrothermal Method
• Determination of the Heat of Fusion of Ice by Mixing Method
• Measurement of the Heat of Vaporization of Water by Mixing Method
• Determination of Specific Heat Capacity of Solids by Cooling Method
• Measurement of the Heat of Fusion of Ice by Electrothermal Method

Thermometer :

• Digital
• Temperature Range: -50°C to 125°C
• Accuracy: ±0.1°C

Stirring System :

• Program-Controlled Motor Stirrer
• Speed: 180 rpm

Voltage Output :

• DC, 2–22.0 V (2 A)

DC Energy Meter :

• Measuring Range: 0–99999.9 J
• Six-Digit LED Display

Mass Measurement Unit :

• Range: 0–600.00 g
• Accuracy: ±0.01 g
• Five-Digit LCD Display

Timer :

• Range: 0–99 Minutes 59.9 Seconds
• Accuracy: 0.1 s

Micro Volume Meter :

• Range: 0–1.00 ml
• Accuracy: 0.01 ml

Other Features :

• Liquid Micro-Volume Adjustment Device
• Water Vaporization Apparatus
