Thermal Conductivity Unit for Heat Physics Lab

This Thermal Conductivity Unit for Heat Physics Lab is designed for studying heat conduction and determining the thermal conductivity of poor conducting materials using the steady-state method. The apparatus enables users to investigate heat transfer through insulating materials by establishing thermal equilibrium and measuring temperature gradients across test specimens. Equipped with a microprocessor-controlled heating system and precision digital temperature sensors, the apparatus provides stable operating conditions and reliable measurements. It is particularly suitable for evaluating the thermal properties of low-conductivity materials such as rubber and bakelite, making it an excellent platform for thermal physics and heat transfer studies.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Measure the Thermal Conductivity of Poor Conductors Using the Steady-State Method
• Determine the Thermal Conductivity of Rubber Specimens
• Determine the Thermal Conductivity of Bakelite Specimens
• Study Temperature Distribution Under Steady-State Conditions
• Calculate Heat Conduction Rates Using Experimental Data
• Investigate Cooling Rates and Heat Transfer Characteristics
• Perform Accurate Temperature Measurements Using Digital Sensors

Educational Objectives

• Understand the Principles of Thermal Conductivity and Heat Transfer
• Learn the Steady-State Method for Thermal Conductivity Measurement
• Study the Thermal Behavior of Insulating Materials
• Develop Skills in Temperature Measurement and Data Analysis
• Explore the Relationship Between Temperature Gradients and Heat Flow
• Gain Practical Experience in Thermal Physics Experimentation

Thermometer :

• Measuring Range: 0–100°C

Temperature Controller :

• Control Range: Ambient Temperature to 80°C
• Resolution: 0.1°C

Experimental Specimens :

• Rubber Specimen
• Bakelite Specimen

Measurement Uncertainty :

• Less Than 6%

Standard Supply

• Main Unit with Heater and Temperature Controller × 1
• Rubber Specimen Disc × 1
• Bakelite Specimen Disc × 1
• Copper Heat Sink Disc × 1
• Digital Temperature Sensors × 2
• Instruction Manual × 1

• High-Performance Temperature Controller and Sensor
• Simple Structure with Stable and Reliable Operation
• Accurate and Repeatable Measurements
• Cost-Effective Educational Apparatus
