ATENG 10774 — Thermal Effects of Microwaves in Biomedicine Unit
Bench-top unit.
Anodized aluminum frame and panels made of painted steel.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
- Instrument for microwave therapy:
- Application of microwave therapy:
- Adjustable treatment time: 1 – 30 minutes.
ATENG 10774 detail
- Pulsed peak power with 50 Ohm load: 1600 W.
- Continuous peak power with 50 Ohm load: 250 W.
- Insulation class: type BF, class I.
- Risk class (93/42/CEE): IIB.
LCD display to view and check the operating parameters.
Encoder to control de microwaves power.
Two buttons to control the therapy mode and the treatment time.
Movable arm and applicator for a better positioning of the microwave instrument radiation.
- Arm model or biological tissue simulator:
Three layers of materials with acoustic properties and thicknesses similar to layers of skin, soft tissue (fat and muscle) and bone.
Three “J” type temperature sensors located at different heights within the simulator.
Cables and accessories, for normal operation.
