Thermistor Characteristic Physics Lab Experiments Setup by ATICO EXPORT

This experiment system is designed for studying the characteristics and applications of thermistors. It enables the investigation of both Positive Temperature Coefficient (PTC) and Negative Temperature Coefficient (NTC) thermistors and their resistance variations with temperature. The system provides a comprehensive platform for understanding temperature-sensitive electronic components and their practical applications. Integrated temperature control, temperature source, voltmeter, and ammeter modules ensure convenient operation and accurate measurement.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Study of thermistor operating principles
• Investigation of NTC thermistor characteristics
• Investigation of PTC thermistor characteristics
• Analysis of resistance variation with temperature
• Measurement of temperature-resistance relationships
• Study of temperature sensing and control applications
• Understanding the practical use of thermistors in electronic circuits
• Development of skills in temperature measurement and data analysis

Host :

• Main Chassis Size: 520 mm × 318 mm × 145 mm

Temperature Controller :

• Full-Range Adjustable Setting
• Relay Output Contact Capacity: 3 A / 220 V Resistive Load or Equivalent

Voltmeter :

• Measuring Ranges: 200 mV, 2 V, 20 V, 200 V
• Four Selectable Ranges
• 3½-Digit Display

Ammeter :

• Accuracy: 0.2%
• Four Selectable Ranges: 200 μA, 2 mA, 20 mA, 200 mA
• 3½-Digit Display

Thermistors :

• NTC: 100 Ω
• PTC: 200–300 Ω
• Material Constant: 1980–3630 K
• Rated Power: 0.25 W
