Thermoelectric Refrigeration Physics Lab Experiment Setup by ATICO EXPORT

This experiment system is designed for studying thermoelectric effects, temperature sensing technologies, and temperature measurement methods. It enables the investigation of semiconductor thermoelectric materials, thermistors, PN junction temperature characteristics, resistance thermometers, and thermocouples. The system provides precise temperature control for conducting a wide range of thermal and electronic experiments, making it suitable for university laboratories and advanced physics education.

Manufactured by Atico Export India.

Experimental Principle and Content

• Study of the Peltier Effect in Semiconductor Thermoelectric Materials for Cooling and Heating Applications
• Investigation of the Relationship Between PN Junction Forward Voltage Drop and Temperature
• Study of the Seebeck Effect
• Measurement of Thermoelectric Potential in Metal Materials
• Investigation of Semiconductor Thermistor Characteristics
• Resistance Thermometer and Unbalanced DC Bridge Experiment
• Determination of the Temperature Coefficient of Resistance of Metals
• Design and Development of Digital Thermometers

Main Components :

• Temperature Controller
• Semiconductor Refrigeration Module
• Accessories

High-Precision Digital Intelligent Temperature Control System :

• Temperature Control Range: Room Temperature to 120°C
• Cooling Range: -10°C to Room Temperature
• Temperature Control Accuracy: ±0.1°C
• Stability: ±0.1°C

Digital Temperature Sensor :

• Measurement Range: -50°C to 125°C
• Accuracy: ±0.1°C
• Digital Display

Digital DC Regulated Power Supply :

• 0–15 V (2 A)
• Short-Circuit Protection

Digital Constant Current Source :

• 0–1000 μA

Fixed DC Power Supply :

• ±12 V
