Three Phase Half Full Wave Uncontrolled Rectifier

The Three Phase Half-Full Wave Uncontrolled Rectifier Trainer is designed for practical study of three-phase half-full wave rectification and AC-to-DC conversion. It helps students understand diode rectification, phase-wise operation, and resistive load characteristics through hands-on experiments. The trainer includes an isolated AC supply, digital meters, power diodes, a rheostat load, short-circuit protection, and three-phase indication for clear practical operation. The unit is housed in a metal cabinet with a clearly printed insulated circuit board. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Power Supply:

• Isolated supply: 0–440 V / 110 V AC at 1 A.
• Mains operated: 440 V, 50 Hz ±10%.

Digital Meters:

• Voltmeter: 2000 V AC.
• Voltmeter: 2000 V DC.
• Ammeter: 2 A DC.

Components Mounted on Panel:

• 6 power diodes.

Load:

• Rheostat as resistive load.

• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• 4 mm patch cords.
• Short-circuit protection through 3-pole MCB.
• Three-phase indication through red, yellow, and blue indicators.
• High-voltage test points with 4 mm safety sockets.
• Housed in a metal cabinet.
• Trainer size: 18 × 12 inches.
