Three Phase Slip Ring Machine 10HP

Three Phase slip ring induction motors, the rotor is actually –wound on an armature–. The windings are brought out to terminals by a set of three –slip rings– on the armature shaft. Three phase winding both stator and rotor induction motor with slip ring at the rotor end. Winding terminals of K, L & M brought out for external Rotor Resistance Starter application.

Nominal Power :

• 7500W / 10HP

Nominal Voltage :

• 415VAC

Current :

• 15A

Nominal Speed :

• 1500 rpm

Pole :

• 4

Type :

• Wound Rotor

Frequency :

• 50 Hz

Cooling Method :

• Self Cooling

Material :

• Cast Iron

Protection :

• IP55

Terminals :

• 4mm Safety Socket

Base :

• Complete With Cart Installed With Heavy Duty Castor Wheel With Lock In Front

Manual :

• Instruction & Experimental

Coupling & Sleeve :

• Option

Weight :

• 96Kg

Typical Experimental :

• Rotor Resistance Starting
• Speed Control
• Torque Speed Test
