Timken Tester for Oil Fuel and Petroleum Testing Instruments

The Timken Extreme Pressure Test Rig evaluates the extreme pressure properties of lubricating greases and lubricating fluids. A steel test cup rotating at 800 RPM is pressed against a steel test block, carrying the test sample into sliding contact. The load at the contact is progressively increased to determine the score value and OK load value. The system features a precision spindle mounted on a rugged frame, a loading lever with a spring-loaded pan, a friction lever with sliding weight and pan, a load cell for measuring normal load, a lubricating fluid recirculation system, and an automatic grease feeder. It also includes an oil reservoir with a heating system, a frequency-drive motor, dead weights, and counterweights. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricant extreme pressure testing applications.

Motor and Drive:

• 2 HP motor with frequency drive

Test Rig Specifications:

• Test rig outer diameter: 49.22 mm
• Test block dimensions: 12.32 × 12.32 × 19.1 mm
• Rotational speed: 100 to 800 RPM
• Rate of loading: 0.9 to 1.3 kg/sec
• Dead weights: 52 kg
• Loading arm ratio: 1:10

Fluid Recirculation System:

• Automatic fluid recirculation feeder
• Reservoir capacity: 3 L
• Oil reservoir with heating system

Automatic Grease Feeder:

• Feed rate: 45 ± 10 g/min

Control System:

• Load cell for normal load measurement
• Digital load indicator
• Preset timer: 99 hours, 59 minutes, 59 seconds
• Preset temperature controller: Up to 100°C

Standard Accessories:

• Test cups: 25
• Test specimens: 25
• Power cables
• Calibration reports
• Tool kit
• Friction lever and weights
• Loading lever with spring-loaded pan
• Dead weights and counterweights
