To Study L to C Transmission Line for Physics Lab Experiments

L.C. Transmission Line Experimental Training Board is designed specifically to study voltage distribution along an L.C. transmission line in the form of an artificial transmission line. The setup helps students study the Ferranti Effect, distortionless line, and velocity of propagation.

Physics Lab Experiments Setup from Atico Exports.

Objective :

• To Study Voltage Distribution Along an L.C. Transmission Line
• To Study Voltage Distribution Along an Open-Circuit Line
• To Study Voltage Distribution Along a Short-Circuit Line
• To Study the Ferranti Effect
• To Study a Distortionless Line
• To Study the Velocity of Propagation

Artificial Transmission Line :

• Consists of 20 Sections
• Each Section Contains Two R.F. Chokes and One Condenser
• Connections Provided Through Terminals on the Front Panel

Metal Connectors :

• 16 Metal Connectors Provided for Connections Between Terminals

Patch Cords :

• Adequate Number of Patch Cords
• Stackable from Both Ends
• 4 mm Spring-Loaded Plugs
• Length: 50 cm

Terminal Sockets :

• High-Quality and Reliable Terminal Sockets
• Provided at Suitable Positions on the Panel for Connections and Observation of Waveforms

Instructional Support :

• Detailed Operating Instructions
• Objective
• Theory
• Design Procedures
• Report Suggestions
• Book References

Weight :

• Approximately 5.1 kg

Dimensions (W × H × D) :

• 415 × 165 × 315 mm

Other Apparatus Required :

• V.T.V.M.
• AF Generator
• Decade Resistance Box
• Dual-Trace CRO

List of Accessories :

Red Patch Cords :

• 4 mm
• Length: 50 cm
• Quantity: 4

Black Patch Cord :

• 4 mm
• Length: 50 cm
• Quantity: 1

Aluminum Strips for Connection :

• Quantity: 16
