To Study R to C Transmission Line at 50Hz for Physics Lab Experiments

R.C. Transmission Line Experimental Training Board is designed specifically for the study of R.C. transmission lines at 50 Hz. The setup allows the variation in magnitude and phase of voltage after each section to be studied for different input voltages at 50 Hz.

A phase shift of approximately 2π can be observed across 20 sections. The setup provides practical experience for science and engineering students.

Physics Lab Experiments Setup from Atico Exports.

Objective :

• To Study the R.C. Transmission Line at 50 Hz
• To Plot a Curve Showing the Variation of Magnitude and Phase of Voltages Along the R.C. Ladder Network and Determine the Attenuation

AC Step-Down Transformer :

• Secondary Tappings: 50, 100, and 200 V at 100 mA

R.C. Sections :

• 20 Sections of Resistance and Capacitance
• Connections Provided on Sockets

Control and Protection :

• Mains ON/OFF Switch
• Fuse
• Jewel Light

Operating Supply :

• 230 V AC ±10%
• Frequency: 50 Hz

Patch Cords :

• Adequate Number of Patch Cords Provided
• Stackable from Rear Ends
• 4 mm Spring-Loaded Plugs
• Length: 50 cm

Panel Details :

• Operating Instructions and Details Provided at Appropriate Locations on the Panel for Easy Connection and Observation of Waveforms

Instructional Support :

• Detailed Operating Instructions
• Object Details
• Theory
• Design Procedures
• Report Suggestions
• Book References

Weight :

• Approximately 5.5 kg

Dimensions (W × H × D) :

• 415 × 165 × 315 mm

Other Apparatus Required :

• 3¾-Digit Digital Multimeter
