Torsion of bars

Torsion occurs primarily on axles and drive shafts in motor vehicles and machines. The torsion occurring in the shaft cause cross-sections of the shaft to be pushed together around the longitudinal axis. When a torque is applied to a shaft the cross-section remains flat and no warpage occurs. Learn about Torsion of bars suppliers for optimal educational outcomes..

• elastic torsion of bars
• 2 movable support blocks with clamping chuck for mounting of bars, 1 fixed and 1 floating bearing
• 2 movable angle indicators clampable to the bar
• 4 bars: round bar with full cross-section, tube, longitudinally slotted tube, square tube
• application of load to the bar by a mass disk, a deflection roller and weights
• storage system to house the components
• experimental setup in frame SE 112
