Torsion test, 30Nm

The torsion test is a destructive testing method that studies the plastic behaviour of materials. In practice, components that are twisted in their application (e. g. Learn about Torsion test, 30Nm engineering_mechanics_trainers5 India for optimal educational outcomes.. screws, shafts, axles, wires and springs) are studied with this test method.

• torsion tests with different metallic specimens to fracture
• manual generation of the twisting moment by means of handwheel and worm gear
• specify the input angle via handwheel
• long and short specimens of steel, aluminium, brass
• movable measuring device for different specimen lengths
• measure the test moment by means of strain-gauge measuring shaft and measuring amplifier
• strain-gauge measuring shaft with compensation for inherent deformation
• twisting angle measured by incremental encoder
• electronic measuring amplifier with touch panel to display twisting moment and twisting angle
• software for data acquisition via USB under Windows 11
