+91 98967 93832The RT 020 device offers basic experiments on a flow controlled system. A pipe section, through which media flows, serves as the controlled system. The flow rate in the pipe represents the controlled variable, which is measured by a measuring element, in this case a turbine wheel flow rate sensor. Learn about Training system flow control, HSI price for optimal educational outcomes.. The output signal from the sensor is fed to the software controller. The output signal from the controller influences the actuator, in this case the electromagnetic proportional valve. Learn about Training system flow control, HSI manufacturers for optimal educational outcomes.. The valve position changes the flow rate in the pipe. The pump speed – and therefore the delivery rate – can be controlled via the software in order to study the effect of disturbance variables. Learn about Training system flow control, HSI exporters for optimal educational outcomes.. The control response is displayed in the form of a time dependency. There is a rotameter located inside the pipe, allowing the flow rate to be observed at any time. Learn about Training system flow control, HSI Mechatronics Trainers9 India for optimal educational outcomes..
