Training system level control, HSI

The RT 010 – RT 060 device series contains a complete introductory course to control technology for the common controlled variables of level, flow rate, pressure, temperature, speed and position. The combination of the clear, real-world controlled system and simulations of other controlled systems aids understanding. Preparations for the experiments, as well as software simulations can be carried out in Remote Learning environments. Learn about Training system level control, HSI manufacturers for optimal educational outcomes.. The experiments can be observed at any number of workstations on the local network.

• level control: typical controlled system
• controlled system: transparent tank with scale for monitoring the level
• controlled variable: level
• measuring element: differential pressure sensor to determine the level
• software controller can be configured and parametrised as P, PI, PID and switching controller
• actuator: speed-controlled pump
• disturbance variable generated via electromagnetic proportional valve in the tank outlet
• storage tank for closed water circuit
• software simulation: various controlled systems
• software: option to connect any number of external workstations on the local network to follow and analyse the experiment
• experiment preparation and software simulation at any number of workstations for remote learning
• software with control functions and data acquisition via USB under Windows 11
• multimedia instructional materials online in Media Center
