Training system position control, HSI

The RT 060 device offers basic experiments on a position controlled system. A moving slide, which is moved by a toothed belt, is used as the controlled system. The position represents the controlled variable. Learn about Training system position control, HSI for educational labs for optimal educational outcomes.. The position of the slide is determined by a measuring element, in this case a rotary encoder. The output signal from the sensor is fed to the software controller. Learn about Training system position control, HSI Mechatronics Trainers9 India for optimal educational outcomes.. The output signal from the controller controls the actuator, in this case the motor. In this way the slide is pulled into a new position on the toothed belt. Learn about Training system position control, HSI price for optimal educational outcomes.. The motor is automatically switched off when the moving slide reaches one of the two end positions. The current position can be read directly off a steel scale at any time. Learn about Training system position control, HSI exporters for optimal educational outcomes.. The control response is displayed in the form of a time dependency. A transparent protective cover allows the experiments to be observed safely. Learn about Training system position control, HSI manufacturers for optimal educational outcomes..

• position control: typical controlled system
• controlled system: moving slide with linear track
• controlled variable: position of the moving slide
• measuring element: rotary encoder (multi-turn potentiometer) as position sensor
• software controller can be configured and parametrised as P, PI, PID and switching controller
• actuator: motor
• steel scale for observing the position
• transparent protective cover over the experimental setup
• 2 microswitches for end position shut-off
• software simulation: various controlled systems
• software: option to connect any number of external workstations on the local network to follow and analyse the experiment
• experiment preparation and software simulation at any number of workstations for remote learning
• software with control functions and data acquisition via USB under Windows 11
• multimedia instructional materials online in Media Center
