Training system temperature control, HSI

The RT 040 device offers basic experiments on a temperature controlled system. A metal rod is used as the controlled system. The temperature of the metal rod represents the controlled variable. Learn about Training system temperature control, HSI for educational labs for optimal educational outcomes.. The temperature is measured at three different positions using thermistors (PTC). One measured value is fed to the software controller at a time. Learn about Training system temperature control, HSI manufacturers for optimal educational outcomes.. The other two values are recorded. This makes it possible to replicate different controlled system responses. Learn about Training system temperature control, HSI exporters for optimal educational outcomes.. The output signal from the controller is used to control the Peltier element actuator. The Peltier element has a hot and a cold side. Learn about Training system temperature control, HSI price for optimal educational outcomes.. This allows either heating or cooling power to be supplied to the metal rod. The software can be used to control a fan that dissipates heat energy in order to study the effects of disturbance variables. Learn about Training system temperature control, HSI specifications for optimal educational outcomes.. The control response is displayed in the form of a time dependency. There is a dial-gauge thermometer located on the metal rod, allowing the temperature to be read directly at any time. Learn about Training system temperature control, HSI Mechatronics Trainers9 India for optimal educational outcomes..

• temperature control: typical controlled system
• controlled system: metal rod in a heat-insulated sheath
• controlled variable: temperature
• measuring element: 3x temperature sensors at different positions along the metal rod to display lag time, PT1, PT2, PT3 system response
• software controller can be configured and parametrised as P, PI, PID and switching controller
• actuator: Peltier element as heater and chiller
• disturbance variable generated via a fan that dissipates heat energy
• observing temperature via dial-gauge thermometer
• software simulation: various controlled systems
• software: option to connect any number of external workstations on the local network to follow and analyse the experiment
• experiment preparation and software simulation at any number of workstations for remote learning
• software with control functions and data acquisition via USB under Windows 11
• multimedia instructional materials online in Media Center
