Transformer System Trainer

Experiments :

• Single Phase Transformer
• Turns Ratio Test
• Open Circuit Test
• Short Circuit Test
• Load Test
• Transformer Winding Polarity and Interconnection Method 1
• Transformer Winding Polarity and Interconnection Method 2 & 3

Three Phase Transformer

• Wiring Configuration
• Star-Star Connection
• Star-Delta Connection
• Star-Zigzag Connection
• Delta-Star Connection
• Delta-Delta Connection
• Delta-Zigzag Connection

Loading Test

• Star-Star Connection – Resistive Load
• Star-Delta Connection – Resistive Load
• Delta-Delta Connection – Resistive Load
• Delta-Star Connection – Resistive Load

The Transformers System Trainer is a complete teaching package focused on electrical power conversion and power distribution in single and three phase supplies. The package is supplied with manuals and laboratory notes that provide a step-by-step guide to setting-up and carrying-out the range of assignments. The system is based around transformers rated at 300VA for single phase and 1KVA for three phases. Power supplies, loading and instrumentation are provided in the form of panels mounted into a bench-standing frame fitted with swivel castors. The training system is designed to ensure safe experimentation for students.

SINGLE PHASE TRANSFORMER

• The transformer is compact and self-contained unit. The input of the transformer shall be 240 V ° 5V and the output has two (2) level of output voltage (240V°5% and 120V°5%). The output either can be one (1) winding with center-tapped or separately two winding.
• All internal components and circuits represented by schematic diagram on the front panel with 4 mm safety terminal sockets at the input and output point. The transformer protected against overload and short-circuits faults by means of fuses.
• Single phase transformer with spitted winding core type.

Transformer 1:

• Power rating : 500VA, 50 Hz.
• Input 1 : 240V°5%.
• Output 1 : 240V°5%.
• Transformer 2:
• Power rating : 500VA, 50 Hz.
• Input 2 : 240V°5%.
• Output 2 : 120V°5%

THREE PHASE TRANSFORMER

• Three phase transformer with spitted winding core type designed in didactical version.

• Each primary and secondary winding are divided in two sections to allow many possibilities of connection including star, delta and zig-zag.

• Primary Voltage: Three Phase 415V (3x2x207.50V)

• Secondary Voltage: Three Phase 240V (3x2x120V)

• Power: 1000VA

• Frequency 50Hz

• Dimensions: 50x29x21cm (LXWXH)

• Weight: 15kg

Resistive Load Unit

Single-Three phase Resistive Load 7 steps variable per phase

• Max Power: 300 watt
• Voltage: 220/380 Volt
• Unit Type: Top Table
• Can be connected in Series, Parallel, Star and Delta configurations.
• Can be connected to AC Single and 3 Phase sources.
• Controlled by 3 x 3 circuit breaker switches for 7 steps selection.

INDUCTIVE LOAD UNIT

Single-Three phase Inductive Load 7steps variable per phase

• Max Power: 300VAR
• Voltage: 220/380 Volt
• Unit Type: Top Table
• Can be connected in Series, Parallel, Star and Delta configurations.
• Can be connected to AC Single and 3 Phase sources.
• Controlled by 3 x 3 circuit breaker switches for 7 steps selection.

**CAPACITIVE LOAD UNIT **

Single-Three phase Inductive Load 7 steps variable per phase

• Max Power: 300 VAR
• Voltage: 220/380 Volt
• Unit Type: Top Table
• Can be connected in Series, Parallel, Star and Delta configurations.
• Can be connected to AC Single and 3 Phase sources.
• Controlled by 3 x 3 circuit breaker switches for 7 steps selection.

THREE PHASE POWER QUALITY METER

Modular design
Display Type: HD LCD Display
Real-Time Measurement

• Phase voltage: V1, V2, V3, Vlnavg Line voltage: V12, V23, V31, Vllavg Current: I1, I2, I3, Iavg, In Active power: per phase and total active power Reactive power: per phase and total reactive power Apparent power: per phase and total apparent power Power factor: per phase and total power factor Total frequency

Energy And Demand

• Four quadrant active energy: Import, Export, Total, Net Four quadrant reactive energy: Import, Export, Total, Net Active, Reactive, Apparent demand o Power Quality Analysis
• Voltage unbalance Current unbalance Voltage THD (Total harmonic distortion), Odd-even harmonic distortion Voltage individual harmonics, Crest factor Current THD, Odd-even harmonic distortion Current individual harmonics, K factor

Communication

• Ethernet 10/100M network port

Trend Logging

• Phase voltage Line voltage Current Active power Reactive power Apparent power Power factor Frequency Three-phase unbalance Active energy Reactive energy Apparent energy Phase

Settable Logging Interval

• Logging from 1min to 60min, interval settable

Software Accessibility

• 4 Tariffs (DataLog) Sharp, peak, flat, valley in different season and schedule (TOU)
• PowerMeter Management Software Interface**
• Accuracy: °0.5%
• Protection: Fuse
• Power Supply: AC240VAC, 50Hz
• Terminals: 4mm Safety Socket
• Unit Type : Panel H2

UNIVERSAL AC/DC POWER SUPPLY

Specification

• Power Input Requirement: Three Phase 240V/415V, 50Hz
• Connection: 3P+N+PE Output terminations by using 4mm terminals socket.
• Input fed with AC 5 pin plug 32A AC Plug and Socket.
• Pilot lamps provided to indicate all live supplies.
• With On/Off Switch
• Fuse Protection.

Output Supply Section

• Fixed Single Phase AC Power Supply: 3 x 240V AC; 5A AC (Phase To Neutral; R-N, B-N, Y-N)
• Fixed Three Phase AC Power Supply: 3 x 450V AC; 5A AC (Phase To Phase; R-Y, Y-B, B-R)
• Adjustable Single Phase & Three Phase AC / DC Power Supply (Simultaneously):
• 3 x 0 ~ 450VAC; 5A AC (Phase To Phase)
• 3 x 0 ~ 240VAC; 5A AC (Phase To Neutral)
• 1 x 0 ~ 450VDC; 5A DC (DC Output)

DIGITAL AC VOLTMETER (2 UNITS)

• Measurement range : AC 0 ~ 600V
• Display : 3 ° digits 14.2 mm LED
• Accuracy : ° 0.2% ° 1 digit
• Resolution : 1V
• Input impedance : 1M°
• Power source : 220Vac, 50/60 Hz
• Unit Type : Panel H1
• Terminals: 4mm Safety Sockets

DIGITAL AC AMMETER (2 UNITS)

• Measurement range : AC 0 ~ 5A
• Display : 3 ° digits 14.2 mm LED
• Accuracy : ° 0.3% ° 1 digit
• Resolution : 0.01 A
• Input impedance : < 0.1°
• Power source : 220Vac, 50/60 Hz
• Unit Type : Panel H1
• Terminals: 4mm Safety Sockets

POWER MANAGEMENT SOFTWARE

• PC software for Power Quality Meter
• Web browse data
• True-RMS measuring parameters
• ANSI and IEC 0.2 accuracy class
• Power quality analysis
• 4 quadrant energy
• Data logging
• Measure individual harmonics from 2nd to 49th
• TOU, 4 Tariffs, 6 Seasons, 6 Schedules

4MM SAFETY STACKABLE TEST LEAD SET & 19MM SHUNT / BRIDGING PLUG SET

• The set consists of 2 type lead set and 2 type bridging plug set in 5 different coded colors and lengths chosen to allow the realization of all experiment manual.
• Leads are capable of 15A current safety plugs.
• Safety Terminal Socket (4mm): 25cm x 15 units; 50cm x 20 units; 100cm x 15 units
• 19mm Bridging Plug Set x 10 units
• 19mm Bridging Plug Set (Stackable) x 10 units

EXPERIMENTAL TABLE

• Workbench Table Top
• Material: Compress Board

Dimension:

• Thickness: 25mm
• Length: 1500mm
• Width: 800mm
• Height: 800mm

Support Structure

Material:

• 2– x 2– Hollow Steel Epoxy Coated
• Thickness: 2mm
• Castor Wheels (Front With Lock)
• Lower Cabinet with 3 Storage Drawers with center Lock (Optional -03D)

EXPERIMENT PANEL FRAME

• Din Standard A4 With Two Shelves
• Side Frame: T Shape
• Horizontal U-Bar: Top and Bottom
• Horizontal H-Bar: Centre
• Material: 2mm Thickness Steel Epoxy Coated

Dimension:

• Length: 1450mm
• Width: 20mm
• Height: 300mm

Complete with Test Lead Set Holder

• Two Location: Left & Right
• 7 Slots for 4mm Stackable Safety Test Lead Sets

• This device includes some basic experiment units and can be expanded to advanced ones. Modular design makes it easy to use and maintain
• Circuit diagrams or block diagrams are printed on the panel of the transformers
• All the test points and connection terminals are brought out on the front for easy access and measurement by 4mm safety socket terminals
• Connection terminals are standard 4mm safety stackable test leads sets
