Triaxial Mechanical Properties Testing System oil and petroleum testing instruments by ATICO EXPORT

The triaxial mechanical properties testing system is specially designed to measure the mechanical properties of oilwell cement. It has the ability to measure compressive strength, Young’s modulus, Poisson’s ratio and tensile strength of cement samples under in-situ conditions.

Load frame capacity :

• 112,400 lb (500 kN)

Stroke :

• 4" (100 mm)

Maximum temperature :

• 400°F (204.4°C)

Maximum pressure :

• 10,000 PSI (69.0 MPa)

Size :

• 52.5" × 35.5" × 84.5" (133 × 90 × 215 cm)

Weight :

• 3,485 lb (1,580 kg)

Crated size :

• 82" × 48" × 94" (208 × 122 × 239 cm)

Crated weight :

• 4,050 lb (1,837 kg)

Requirements :

• Air supply: 100 PSI (690 kPa) recommended, 150 PSI (1,035 kPa) maximum, ¼" NPT connector
• Power supply: 230 - 240 Volt, 50/60 Hz, 10 Amps

• Physically measures the mechanical properties of set cement:
• Compressive strength
• Young's modulus
• Poisson's ratio
• Brazilian splitting tensile strength
• Temperature control up to 400°F (204.4°C) and confining pressure control up to 10,000 PSI (68.95 MPa) are available to simulate down-hole conditions with either oil or water as a pressure medium
• Accommodates cube samples up to 2.0" × 2.0" and cylindrical samples up to 2.0" in diameter and 5.0" in length
• Utilizes digital servo-controlled pressure and load for improved accuracy and stability
• Single, self-contained unit with a compact footprint to save floor space
• Windows®-based system control and data acquisition
