Triaxial Testing Machine

Usage :

• Used for determining the shear strength parameters of saturated soils from triaxial compression shear tests

Loading Frame :

• Capacity : 50 KN with 6 different speeds

Frame Construction :

• Two pillar type with enclosed motor and gear system

Triaxial Cell :

• Suitable for 38 mm dia. soil specimen

Consist of following parts and accessories :-

• Loading Pad (Made of Perspex for 38 mm dia. specimens)
• Pair of Plain Discs (Made of Perspex of 38mm dia. x 6mm thick)
• Pair of Porous Stone (38 mm dia. x 6 mm thick)
• Spilt Sand former for 38 mm dia. specimen
• Plastic Drain Tube

Proving Ring :

• Capacity : 200 kgf (2 KN) with dial gauge (0.002 x 5 mm)

Travel Dial Gauge :

• Range : 0.01 x 25 mm

Lateral Pressure Assembly :

• Provided

Standard Compliance :

• Conforms to IS :2720 - Part 11
