Triple Output DC Power Supply

Display :

• Six 3° digit digital panel meters

Output Configuration :

• Variable Outputs (2 channels):
• 0 to 30V, 0 to 3A (each)

Fixed Output (1 channel) :

• 2.5V / 3.3V / 5V, 3A

Operating Modes :

• Constant Voltage operation
• Constant Current operation

Control and Functionality :

• Independent operation
• Series operation
• Parallel operation
• Tracking operation

Protection Features :

• Overload protection
• Reverse polarity protection

Performance :

• High stability
• Low ripple and noise
• Low cost

Additional Features :

• Output ON/OFF control
• Preset function

Output voltage

Output voltage (continuously variable) :

• (CV) 0 ~ 30V Dual

Setting resolution :

• (CV) 0 ~ 30V Dual

Output current

Output current (continuously variable) :

• (CC) 0 ~ 3A Dual

Setting resolution :

• 0.01A

Series Operation mode :

• 060V, 03A Output

Parallel Operation mode :

• 030V, 06A Output

Voltage regulation characteristics (CV)

Line regulation (with respect to °10% variation in A :

• – 0.01%+3mV

Load regulation (with respect to change from 0 to 100%) :

• – 0.01% + 3mV

Ripple & noise :

• – 2mVrms

Temperature coefficient :

• – 300ppm/°C

Current regulation characteristics (CC)

Line regulation (with respect to °10% variation in AC) :

• – 0.2%+3mA

Load regulation (with respect to change from 0 to 100%) :

• – 0.2%+3mA

Ripple & Noise :

• – 3mA rms

Tracking operation

Tracking error :

• < 0.5% + 10mA of the Master

Series Regulation :

• < 300mA

Digital meter :

• display (Voltmeter/Ammeter)

Display :

• 3° digit panel meter

Accuracy :

• 1% of reading + 2 digit

Voltmeter :

• 199.9V of full scale

Ammeter :

• 19.99A of full scale

Fixed :

• 2.5/3.3/5V;3A output

Line Regulation :

• < 5mV

Voltage accuracy :

• 5V ° 0.25V

Ripple & Noise :

• CV – 2mVrms

Insulation

Chassis and output terminal :

• 20M° or above (DC 500V)

Chassis and AC cord :

• 30M° or above (DC 500V)

General

Operating environment :

-10~40°C, 80% R.H.

Cooling system :

• Fan

Power requirement :

• 240V ° 10% 50Hz

Case dimensions (WxHxD) mm :

• 250x155x330

Weight :

• 8 kg

Accessories :

• Power Cord, Manual, Output Cable
