Tubular HTST / UHT Pilot System

A cost-effective HTST/UHT pilot-scale processing system based on tubular heat exchanger technology. Suitable for nutraceutical liquids, supplements, and pharmaceutical formulations.

The system combines heating, controls, and instrumentation in a compact stainless steel configuration suitable for laboratory and pilot-scale use.

Flow rate: 20–100 L/hr
Maximum temperature: 165°C
Working pressure: Up to 24 bar
Product volume: Approx. 1 L
Material: 316 stainless steel

• Economical pilot-scale system
• Compact footprint
• Low product hold-up
• Continuous operation
• Sterilisation-in-place option
• Touchscreen control
• Integrated CIP
• Suitable for aseptic processing
