Tubular reactors are continuously operated reactors. Tubular reactors make possible the cost-effective production of large product quantities with consistent quality.
Technical Specifications
continuous tubular reactor to carry out a saponification reaction
10 tubular heat exchangers as reactor
2 identical pumps to convey the reactants
adjustment of the volumetric flow rates of the reactants at the pumps
preheating of the reactants with 2 stainless steel coiled tubes
T-piece for mixing the preheated reactants
hot water tank with temperature control
measurements for electrical conductivity: at the inlet, centre and at the outlet of the reactor
measurement of conductivity and temperature with 3 combined sensors
GUNT software for data acquisition via USB under Windows 11
