Tunnel Diode Characteristics

EXPERIMENT: PLOTTING I-V CHARACTERISTICS IN FORWARD BIAS FOR A GIVEN TUNNEL DIODE & DETERMINATION OF PEAK AND VALLEY VOLTAGES AND CURRENTS

EXPERIMENT SETUP CONSISTS OF:

• Tunnel Diode Characteristics Kit – Variable regulated constant-current source power supply, digital voltmeter and digital ammeter, with tunnel diode connected in circuit
• Set of Patch Cords

Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.
