U-Shape Box Apparatus

The apparatus consists of a mild steel vessel that is fully divided by a middle wall into two sections; an opening with a sliding gate is fitted between the two sections.

Usage :

• Used to determine the filling and passing ability of self-compacting concrete (SCC).

Construction :

• Solid-Robust Construction

Material :

• Stainless Steel

Shape :

• U Shape Box

U-Shaped Box :

• Left-hand Section is filled with about 20 litres of concrete, then gate is lifted and the concrete flows upwards into the other section

Rebars :

• 3 Nos., Dia. 12 mm

Reinforcing Bars :

• installed at gate with centre to centre spacing of 50 mm and bar to clear spacing of 35 mm

Mounting :

• Frame with fixing mechanism

Accessories Included :

• Trowel
• Scoop
• Stopwatch
