U-Shape Double Manometer

With the U-Shape Double Manometer, the study of different pressures is facilitated for operation with the Pitot tube. The U-Shape Double Manometer allows finding the pressure between two points or two fluids.

ATENG 11779 — U-Shape Double Manometer

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

Bench-top unit.

Anodized aluminum frame and panels made of painted steel. Vertical position.

• Main metallic elements made of stainless steel. Eight manometric tubes, length: 500 mm.
• Inclination: 30° approx. Tubes inner diameter: 8 mm, to avoid bubbles.
• Twenty manometric tubes, length: 250 mm. Air pump for pressurization.
• Tubes inner diameter: 8 mm, to avoid bubbles. Eight points for differential pressure measurement, with key.
  Water tank for filling. Common collector.
  Twenty points for differential pressure measurement, with key.
  Non-return valve.
  Common collector.
  Drain valve.
  Drain valve.
• Millimeter precision rules, length: 500 mm.
• Millimeter precision rules, length: 250 mm.
