Ultrasonic Cement Analyzer Twin Cell 5 KSI petroleum testing instruments by ATICO EXPORT

By measuring the change in velocity of an acoustic signal, the ultrasonic cement analyzer provides a continuous non-destructive method of determining compressive strength as a function of time while at temperature and pressure.

Maximum temperature :

• 400°F (204.4°C)

Maximum pressure :

• 5,000 PSI (34.47 MPa)

Size :

• 24” × 18” × 12” (61 × 46 × 30 cm)

Weight :

• Approx. 70 lb (32 kg)

Requirements :

• Air supply: 100 PSI (690 kPa) recommended, 150 PSI (1,035 kPa) maximum, ¼” NPT connector
• Water supply: 40 - 100 PSI, 40° - 100°F, ¼” NPT connector
• Coolant supply: ¼” NPT connector

Power supply :

• Electronics: 230 - 240 Volt, 50 - 60 Hz, 2 Amp
• Heaters: 230 - 240 Volt, 50 - 60 Hz, 8 Amp

• Cement samples are not destroyed at time intervals
• Self-venting regulators provide accurate pressure control
• Temperature control up to 400°F and pressure control up to 5,000 PSI are available to simulate down-hole conditions
• Unique technology results in a cleaner signal, making transit times and data more accurate
• Data is available instantly on-screen and automatically downloaded to a Microsoft Excel spreadsheet for easy analysis
