Underfloor Heating and/or Heat Source for Heat Pump

The Underfloor Heating and/or Heat Source for Heat Pump, allows the visualization of a piping system that simulates a radiant floor heating system and its functions as a heat sink. It can also be used as a heat source working in conjunction with a heat pump.

ATENG 12745 — Underfloor Heating and/or Heat Source for Heat Pump

Anodized aluminum frame and panels made of painted steel.

The unit includes wheels to facilitate its mobility.

Main metallic elements made of stainless steel.

Diagram in the front panel with distribution of the elements similar to the real one.

• Pipes:
• Lengths: 10 m, 20 m, 30 m.
• Material: polyethylene.
• Wall thickness: 2 mm.
• Outer diameter: 16 mm.
• Operating pressure: 3 bar max.
• Tank:
• Volume: 200 l.
• Measuring ranges:
• Temperature: six units; range: -50 °C to 180 °C.
• Flow rate: four unit; range: 60 to 3600 l/h.
• 230 V, 50 Hz, single-phase. ATENG 12745 detail
  UL/CSA optional.
  Cables and accessories, for normal operation.
