Unit for studying Forces in a Jib Crane

The Unit for studying Forces in a Jib Crane, allows to determine the forces in the members of the crane jib and to confirm the results obtained with the theoretical calculations and with the graphical results from a force parallelogram.

ATENG 12151 — Unit for studying Forces in a Jib Crane

Bench-top unit.

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

Diagram in the front panel with distribution of the elements similar to the real one.

• The “ATENG 12151” unit mainly consists of:
  Adjustable length bar. It includes a spring balance for compressive forces. Pressure
• force: 0 – 50 N, graduations: 0.5 N.
• Chain. It includes a spring balance for tensile forces. Tensile force: 0 – 50 N,
• graduations: 0.5 N.
• Maximum load on the jib: 60 N.
• Support bar: ATENG 12151 detail
• Material: stainless steel.
• Length: 600 mm.
  Angle meter.
