ATENG 12257 — Unit to Study a Two-Stage Spur Gear Cutaway Model
Bench-top unit with adjustable legs.
Each set includes an aluminum transport case.
Anodized aluminum frame and panels made of painted steel.
Units attached to a base plate with handles to facilitate transport.
ATENG 12253 ATENG 12254
Unit to Study a Worm Gear Cutaway Model Unit to Study a Mitre Gear Cutaway Model
- Housing material: Steel. Housing material: Steel.
- External diameter of the worm screw: 25 mm. Gear ratio: 1:1.
- External diameter of the gear: 60 mm. Number of teeth: 26.
ATENG 12256 ATENG 12257
Unit to Study a Spur Gear Cutaway Model Unit to Study a Two-Stage Spur Gear Cutaway Model
- Housing material: Cast iron/Steel. Housing material: Cast iron/Steel.
- Output cogwheel:
- Number of teeth: 68.
- Drive pinion:
- Number of teeth: 24.
- Allowed torque: 54 N·m.
- Allowed number of revolutions: 2800 min-1.
2
Specifications
ATENG 12259 ATENG 12260
Unit to Study a Planetary Gear Cutaway Model Unit to Study a Variable Speed Trapezoidal Belt Drive
Cutaway Model
- Housing material: Cast iron/Steel.
- One sun gear. Housing material: Cast iron/Steel.
Three planet gears. Toothed belt made of rubber.
Ring gear.
- Maximum output torque: 660 N·m.
- Transmission ratio: 1:5.
ATENG 12262 ATENG 12263
Unit to Study a Control Gear Cutaway Model Unit to Study a Multiple-Disc Clutch Cutaway Model
- Housing material: Cast iron/Steel. Housing material: Cast iron/Steel.
- Output speed: 122 - 610 rpm. Number of discs: 3.
- Output torque: 3 - 6 N·m. Maximum speed: 4000 rpm.
ATENG 12265
Unit to Study a Bearing Cutaway Model
- Housing material: Cast iron/Steel.
- Interior diameter: 20 mm.
ATENG 12253 detail ATENG 12254 detail
ATENG 12263 detail ATENG 12262 detail
ATENG 12259 detail ATENG 12260 detail
