Unit to Study an Angular Needle Valve Cutaway Model

The Unit to Study an Angular Needle Valve Cutaway Model, allows the students to visualize the inner parts of a valve, to evaluate the relation with each other accurately and to understand their function.

ATENG 11900 — Unit to Study an Angular Needle Valve Cutaway Model

Bench-top unit with adjustable legs.

Anodized aluminum frame and panels made of painted steel.

Fixed unit on a base plate with handles for easy transport.

• Angular needle valve:
• Housing material: cast iron/steel.
• Nominal pressure: 16 bar.
• Nominal diameter: DN50.
• Flow: fumes, gases, fluids.
