Unit to Study Rotational Inertia

The Unit to Study Rotational Inertia, has been designed to perform tests for the analysis of the moments of inertia of rotating bodies.

ATENG 12113 — Unit to Study Rotational Inertia

Bench-top unit with adjustable legs.

Anodized aluminum frame and panels made of painted steel.

• The “ATENG 12113” unit consists mainly of:
• Rod-rotation axis with pulley of radius 20 mm.
• Solid and hollow cylinder:
• Weight: 1000 g.
• External diameter: 100 mm.
  ATENG 12113 detail
• Hollow cylinder:
• Weight: 220 g.
• External diameter: 100 mm.
• Rotating hollow rod with adjustable position weights:
• Length: 550 mm.
• Thickness: 1 mm.
• Diameter: 10 mm.
• Marks every 20 mm.
• Weights to hang from the rotating rod:
  Two weights of 100 g.
  Two weights of 200 g.
  Two weights of 400 g.
  Fixed pulley.
  Cord and hanger.
• Two weights to generate the rotation movement: 100 g and 50 g.
  Stopwatch.
