UPS Trainer

The UPS Trainer is designed for practical study of uninterruptible power supply systems, power conversion, and electronic switching. It provides a useful platform for understanding UPS operation through practical circuit testing and measurement. The trainer includes a 10:1 potential divider for CRO measurements, a 60 W bulb as load, short-circuit and overload protection, and high-voltage test points for safe laboratory experimentation. The front panel is built with a high-quality insulated printed circuit board featuring clearly marked circuits and symbols. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Power Supply:

• 0–230 V AC, 2 A.
• Mains operated: 230 V, 50 Hz ±10%.

Components Mounted on Panel:

• MOSFET.
• Analog meter: 230 V AC.
• Output socket.

Load:

• 60 W bulb.

• 10:1 potential divider for CRO.
• Protective cover.
• 60 W bulb provided as load.
• Fuse protection against short-circuit conditions.
• Overload protection through circuit breaker.
• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• 4 mm patch cords.
• High-voltage test points with 4 mm safety sockets.
• Housed in a metal cabinet.
• Trainer size: 18 × 8 inches.
