Vacuum Concentrator Centrifuge ALB767

Vacuum concentrator centrifuge designed to efficiently remove water and organic solvents from samples while operating at speeds up to 2000 r/min. It features a microcontroller unit and hightorque brushless motor for stable performance. The transparent cover allows visual monitoring of samples during the concentration process, while the aluminum alloy chamber is coated with corrosionresistant material. Manufactured by Atico Export with a focus on precision, durability and consistent performance for laboratory testing, research and analytical applications.

Chemical analysis
Biological analysis
Immunoscreening
Food safety analysis
Residue analysis
Liquid chromatography
ADMET and toxicology studies
Polymer chemistry
DNA / RNA purification
Forensic drug testing

Maximum Speed :
2000 r/min

Maximum RCF :
500 � g

Rotor Capacity :
6 � 250 mL

Adapter Capacity :
6 � 2 � 50 mL
6 � 5 � 20 mL

Ambient Temperature :
0�C to 40�C

Noise :
? 50 dB(A)

Temperature Control Range :
Room temperature to 60�C
Without heating

Vacuum Degree :
0.1 mbar

Vacuum Interface :
?10 mm

Maximum Current :
7 A

Total Power :
1.5 kW

Power Supply :
AC 220 V, 50 Hz

Packaging Dimensions :
680 � 470 � 470 mm

Weight :
50 kg

Rotor Selections :

Rotor Name :
Angle Rotor
Angle Rotor
Angle Rotor
Angle Rotor
Swing Plate Rotor
Swing Plate Rotor

Maximum Speed :
2000 r/min
2000 r/min
2000 r/min
2000 r/min
2000 r/min
2000 r/min

Maximum Capacity :
62 � 1.5 mL
12 � 10 mL
6 � 50 mL
6 � 250 mL
2 � 48 holes
2 � 96 holes

Maximum RCF :
500 � g
500 � g
500 � g
500 � g
500 � g
500 � g

Noncontact drive rotation system
Overtemperature warning function
LCD touchscreen monitor with TFT truecolor display
Flexible concentration time
Multiple rotor options
Lownoise operation
Hightorque brushless motor
Transparent cover for sample monitoring
Corrosionresistant chamber

Optional Accessories :
Cold Trap (40�C)
Vacuum Pump
