Vacuum Sieving Device - Alpine Air Jet Sieve Shaker

Vacuum Sieving Device / Alpine Air Jet Sieve Shaker especially for the separation of all fine, dry particle size products and provides the elimination analysis in determining the precise particle size distribution is a measuring device.
Sieving analysis is performed with the orientation of the panel in the device. Operator error short sieving times, high sieving ability, reproducible sieve analysis data are obtained.
Vacuum Sieving Device / Alpine Air Jet Sieve Shaker is available in two different versions, BASIC and PROFESSIONAL, suitable for standard 200 mm - 203 mm laboratory sieves with wide analysis ranges for up to 80% faster and more efficient results compared to other sieving methods.

High Performance Cyclone :

• Vacuum absorbed particles pass through the cyclone Recycle 98%.
• Recovers product
• Prevents filter contamination and extends filter life
• Previous product and other product do not mix
• Can stock 0,5 lt material

Laboratory Scale :

• Quality plastic made.
• 600 g capacity
• High sensitivity
• 0,01 g readability
• 160x160 mm pan
• Built-in battery
• LCD display with backlight
• Standard RS232 output

Industrial Type Vacuum Cleaner :

• High performance industrial type
• 7 lt Container capacity
• 200 Watt Air
• 1000 W Energy use
• Stainless steel Material of the chamber
• 35 mm ID accessory
• 1000 W Maximum engine power
• 220/240 V, 50/60 Hz Power supply

For product quality control and sieve analysis inspection data can be saved to our device, the data can be transferred to a computer or printer all the sieve elimination analysis data print numerically and graphically.

Dimensions :

• Vacuum Sieving Device Basic Model - 350x460x 400
• Vacuum Sieving Device Professional Model - 350x460x 400

Weight (kg) :

• Vacuum Sieving Device Basic Model - 18
• Vacuum Sieving Device Professional Model - 18

Spare Parts & Accessories :

Dimensions :

• High Performance Cyclone - 250x150x750
• Laboratory Scale - 280x180x90
• Industrial Type Vacuum Cleaner - 388x340x525
• Dust Bag for Industrial Type Vacuum Cleaner, Pack of 24 - ---

Weight (kg) :

• High Performance Cyclone - 5,5
• Laboratory Scale - 3
• Industrial Type Vacuum Cleaner - 5,8
• Dust Bag for Industrial Type Vacuum Cleaner, Pack of 24 - ---

Sieve diameter :

• 200 / 203 mm

Analysis range :

• 20 mm - 4 mm

Navigation :

• High definition

Touch screen :

• 7"

Power cord :

• 1 m

Low pressure :

• 12000 Pa

Air flow rate :

• 25-125 mm/h

Speed :

• 30 rpm

Protection class :

• IP 54
