Vebe Consistometer

Standards Compliance :

• Complied as per EN 12350-3, ASTM C1170, ASTM C1176

Application :

• The method is a mechanized variation of the slump test and includes determination of workability of fresh concrete by performing vibration to concrete after removal of the slump cone.
  The assembly is mounted upon a small vibrating table operating at a fixed amplitude and frequency.
  The time to complete the required vibration gives an indication of the concrete workability.

Models :

• AECE225/A - Complies with EN 12350-3 for determining the consistency of fresh concrete by means of the Vebe Time.
  The set consists of vibrating consistometer, cylindrical bucket, slump cone, graduated rod with transparent plate with filling funnel and tamping rod.

• AECE225/B - Complies with ASTM C1170 for determining consistency and density of roller-compacted concrete.
  The set consists of vibrating consistometer, cylindrical bucket, swivel arm with guide sleeve with 50 lb surcharge weight and tamping rod.

• AECE225/C - Complies with ASTM C1176 for making roller-compacted concrete in cylinder molds.
  The set consists of vibrating consistometer, cylindrical bucket, swivel arm with guide sleeve with 20 lb surcharge weight and tamping rod.
