Vehicle air conditioning

Vehicle air conditioning systems are used to cool down the vehicle interior. They usually work on the basis of the recirculating air principle and aspirate the air to be cooled from the interior. The cold air generated in the air conditioning system is transported by a fan into the vehicle interior. Learn about Vehicle air conditioning price for optimal educational outcomes..

• investigation of a typical vehicle air conditioning system for cooling the vehicle interior
• compression refrigeration system with compressor, condenser, filter/drier, expansion valve and evaporator
• electric motor with variable speed as compressor drive
• condenser with fan
• evaporator as air cooler with three-stage fan
• compressor drive via V-belt and magnetic coupling
• simulation of 8 faults via buttons in the connectable box
• system is switched on via ignition lock
• display of temperatures, pressures (refrigerant), flow rate (refrigerant), pick-up current, speed
• refrigerant R513A, GWP: 631
• air conditioning system voltage supply: 12VDC
