Vertical Autoclave ALB568

Vertical Autoclave is a fully automatic sterilization unit with a 120 L capacity for efficient laboratory operations. It operates at a maximum working temperature of 138°C to ensure thorough and reliable sterilization. The unit features a built-in water tank that provides a continuous internal water supply throughout the sterilization process. A touchscreen display automatically shows the operating process status for convenient monitoring and control. Laboratory Equipment from Atico Exports.

• Sterilization of laboratory instruments
• Culture media
• Liquids
• Medical waste
• Research laboratories
• Hospitals
• Pharmaceutical industries
• Microbiology laboratories

Capacity :

• 120 L

Maximum Working Temperature :

• 138°C

Sterilization Temperature Range :

• 105°C to 138°C

Maximum Working Pressure :

• 0.23 MPa

Design Pressure :

• -0.1 to 0.3 MPa

Design Temperature :

• 150°C

Temperature Display Range :

• 0 to 200°C

Pressure Display Range :

• 0 to 0.4 MPa

Dissolution Temperature Range :

• 40 to 100°C

Insulation Temperature Range :

• 40 to 134°C

Sterilization Time :

• 0 to 99 minutes

Display :

• Touchscreen

Chamber Material :

• SUS304 Stainless Steel

Power Consumption :

• 9.4 kW

Power Supply :

• 380 V / 50 Hz / 3-Phase

Chamber Dimensions :

• Φ 450 × 760 mm

Product Dimensions :

• 620 × 760 × 1190 mm

Packaging Dimensions :

• 1250 × 1070 × 1520 mm

Net Weight :

• 145 kg

Gross Weight :

• 250 kg

Standard Accessories :

• Sterilization Baskets × 2 Pcs
• Flexible Temperature Sensor × 1 Pc

• Automatic process control
• Multi-program sterilization
• USB data interface
• Cold air removal
• Steam saturation control
• Built-in water tank
• Touchscreen display
• Automatic process status monitoring
• Fully automatic operation
• Reliable sterilization performance
